SPECIFICATIONS
Circuit: SPDT
Current rating: 2A
Voltage rating: 250VAC
Dielectric withstanding voltage: 1000VAC for 1 minute
Contact resistance: 50mo Max
Inslation resistance: 100Ma Min
Travel: 1. 5mm土0.5mm
Operating Force: 400土150gf
Operating life: 200,000 cycles Min
Solder specifications: 260° C for 5 seconds
Function: Momentary
Operating temperature: -20° C~ +85° C

KLS7-PB12-2-M-RB-R.pdf
