Mount Hole Size:Ф12mm
Switch Rating:100mA/12VDC
Contact Condiguration:1NO1NC
Operation Type:Latching
Operation travel: 2mm
IP degree:IP40,IP65
Mechnical life: > 100,000 times
Electrical Life: > 50,000 times

Specification
Mechanical Life:>100,000 times
Switch Type:Bulit-in switch module
Switch Specification:Ith:100mA,Ui :12VDC
Elecrical Lift:>50,000 times
Panel Thickness:1~10 mm
Torque:5~14 Nm
Operation Stroke:2mm About 2mm

Material
Button:Stainless Steel
Case:Stainless Steel
Base:PBT

KLS7-HBGQ12BF-11Z-S.pdf
