Material:
Plastic parts material: PBT
Copper Material: Brass H62
Silver contact material: silver
cadmium oxide AgCdO

Specification：
1.Rating:3A 250V / 5A 125V
2.Contact R: ≤50mΩ
3.Insulation R: ≥100MΩ
4.Dielectric strengty：1500V～2500V
5.Setting Temperature:-55%%dC～120%%dC
6.Electrical Life:50000 Cycles
7.Machine Life:100000 Cycles
8.Operation Force:0.3N～3.5N
9. Manual Soldering 300℃for 5s

KLS7-KM2-1.pdf
