Nano SIM Card Connector,Tray type,6Pin,H1.55mm,with CD Pin

Model: KLS1-SIM-104
MOQ: 1000 PCS
Payment: L/C, D/A, D/P, T/T
Place_of_Origin China
Delivery_Time: 10 days

Inquiry

Product Details
PDF

Nano SIM Card Connector,Tray type,6Pin,H1.55mm,with CD Pin

Electrical:
Current Rating:1 Amp/Pin.MAX.
Voltage:30V DC.MAX
Low Level Contact Resistance:30mΩ Max.Initially.
Dielectric Withstanding Voltage:500V AC MIN.For 1 minute.
Insulation Resistance:100MΩ Min.500V DC .For 1 minute.
Durability:1500 Cycles.
Operating Temperature: -45ºC~+85ºC

PDF

KLS1-SIM-104.pdf
