Material
Housing:Hing Temperature Thermoplastic
                with G.F,UL94V-0,Black.
Contact:Copper Alloy,t=0.20mm.
Shell:Copper Alloy

Electrical:
Current Rating:1A Max.
Dielectric Withstanding Voltage:
                     100 V AC for 1 min.
Contact Resistance:50mΩ Max.
Insulation Resistance:100MΩ Min.
Total Mating Force:3.57 kgf Max.
Total Unmating Force:1.0 kgf Min.
Temperature Range: -30°C Up To +80°C

KLS1-4240.pdf
