ELECTRICAL
1.Rating: 50mA 12V DC
2.Contact Resistance : 100mΩ Max
3.Insulation Resistance: 100MΩ Min
4.Dielectric Strength : 250V AC for 1min
5.Electrically Life:50000cycles
6.Environment temperature:-30ºC~+80ºC
7.Operating Force: 160/250(±30gf)
8.Seal temperature:260ºC~ 280ºC

Materials:
A. cards: phosphor bronze 0.15, silver
B. Base: LCP, white
C. Reed: 65G
D:Dust film: 0.04, yellow
E.Plastic cover: LCP, white
F. button: LCP, black
G. Cover: phosphor bronze 0.2, silvered

KLS7-TS2405.pdf
