Electrical Specification:
Contact Resistance: 5V 10mA
Insulation Resistance: DC100V / 1min
Dielectric voltage proof: 250V AC(50Hz / 60Hz) /1min

Mechanical Specification:
Operating Force:250±50gf
Full Travel:0.3±0. 1mm
Return Force:50gf min
Stem Strength: 20N.min
Solderability:
(1)Solder temperature:245±5℃
(2)Immersion time:2s±0. 5s

KLS7-TS6617.pdf
