Specification:
Rating: 10mA 12V DC
Size: 16.8 x 14.0 x 15.5mm
PCB Terminal : 5 PIN
Operation Force: 60±15gf
Dielectric Strength: AC 100 V 1 Minute
Insulation Resistance: 500 MΩ Mim
Contact Resistance: 1MΩ Max.
Operating Temperature: -25oC ~ +60oC
Operating Life: 10,000,000 Cycles Min

KLS7-PS-009.pdf
