Electrical :
Rated Voltage:                250V    IEC/EN
Rated Current:                16A      IEC/EN
Cross Section(IEC EN)
Solid conductor:           0.75-1.5mm²
Stranded conductor:    0.75-1.5mm²
Flexible conductor:      0.75-1.5mm²

Materials
Insulation Materials: Polyamide 66,Black,UL 94V-2
Contact: Brass,Nickel Plated
Screw: M2.6, SteelZinc Plated
Number of poles: 3 poles
Strip length : 7mm
Protection Degree: IP30
Operating Temperature: 90°C

KLS2-3237.pdf
