Material:
1.UL2464 26AWG*2P+12C+AL/MY,OD:=7.0mm,Black Jacket.
2.OBD II  Female,Black Insulation,Nickel plated
3.OBD II 16P Male,Black Insulation,Nickel plated:REV:U
4.PVC Black,Overmold,50P

Electrical Characteristics:
1.Voltage: DC 300V 10MΩ/10 ms
2.Contact resistance: 3.0mΩ MAX
3.100% Open,Short,Mis-Wire Testing.

Material:
Housing: ABS,UL94V-0,Color Black
SR: Neylon,UL94V-0,Color Black
Terminal: Brass,Nickel plated

KLS1-OBDII-AF02.pdf
