Parameter:
1- Center Contact: Brass,Gold-plated
2- Body-diecast: Brass,Nickel-plated
3- Insulation: PTFE
4- Electrical
Impedance: 50 Ω
Frequency Range:0~300 MHz Max.
Voltage Rating: 750 volts
Withstand Voltage:2000V
Insulation Resistance:5000 MΩ
Contact resistance:
Centre contact: 5 mΩ Max.
Outer contact: 5 mΩ Max.
5- Mechanical
Mating: 3/8-24 threaded coupling
6- Durability(mating):500(cycles)
