Material:
Housing:LCP,UL94V-0
Contact:Copper Alloy.
            Gold Plating  AT Contact Area
           Tin Plating on the Tails.
Shell:SUS304.Tin Plated

Electrical:
Contact Current Rating: 1.0A Max.
Contact Resistance: 30mΩ Max.
Insulation Resistance: 100MΩ Min.
Dielectric Withstanding Voltage:
                           100V AC R.M.S.
Operating Temperature:-30°C ~ +80°C.

Mechanical Characteristics:
Mating Force: 3.5kgf Max.
Unmating Force: 1.0kgf Min.
Durability:5000 Cycles

KLS1-234-10F1.pdf
