Micro SIM Card Connector,8P+1P With Switch,PUSH PUSH,H1.56mm

  • Model: KLS1-SIM-094
  • MOQ: 1000 PCS
  • Payment: L/C, D/A, D/P, T/T
  • Place_of_Origin China
  • Delivery_Time: 10 days
  • Product Details
  • PDF

Micro SIM Card Connector,8P+1P With Switch,PUSH PUSH,H1.56mm

Material:
Housing:High Temperature Thermoplastic,UL94V-0
Contact:Copper Alloy,Au 1u”,Solder area:Gold Flash;Under plate Ni 40u” Min all over
Shell:SUS,Plated 30U” Ni Overall,Solder area:Gold Flash

Electrical:
Current Rating: 1.0A
Voltage Rating:50V
Contact Resistance:100mΩ Max.
Dielectric Withstanding Voltage:500V AC
Insulation Resistance:1000MΩ Min./250VDC
Operating Temperature: -45ºC~+85ºC
