Order Information

KLS1-   GM   10  –  010   3000

GM:     GPS+GSM
Con. Code:   010: SMA-J  Connector
3000:  Cable Lenges

Specification:
GPS Antenna
Center Frequency: 1575.42±3MHz
Band Width:CF±5MHz
Polarization:RHCP
Gain:5dBic
V.S.W.R:＜1.5
Impendance:50Ω
Axial Ratio:3dB（max）

LAN
Gain:28±2dB
Noise Figure:＜1.5
Filter Insertion Loss:＜3dB
Ex-band Attenuation:12dB@CF+50MHz/16dB@CF-50MHz
Supply Voltage:2.2~5V DC
Current Consumption:5~15mA
V.S.W.R:＜2.0

GSM Antenna
Frequency Range: 824~960MHz/1710~2170MHz
V.S.W.R:＜2.0
Polarization:Linear
Gain: 2.0dBi Max.
Impendance:50Ω
Cable:RG174
Connector:SMA/MCX/FAKRA or others
Radome Material:ABS
Mounting Method:Screw
Operating Temperature :-40℃~+85℃
