CAT 6 UTP Keystone Jack. Category 6A Screened Keystone Jack – Toolless. 10 Gigabit Ethernet application

  • Model: KLS12-DK7007
  • MOQ: 1000 PCS
  • Payment: L/C, D/A, D/P, T/T
  • Place_of_Origin China
  • Delivery_Time: 10 days
  • Product Details
  • PDF

The Cat6 Keystone Jack

The Cat6 jack provided by us comes with a standard RJ45 plug on the outside. While on the inside, wiring slots are in place for a tool-required termination. All of our networking keystone jacks have 568A and 568B color codes on the jacks in addition to the easy trouble free 110 style termination.
Meeting All Requirements
Each RJ45 keystone jack is flame retardant and each is UL verified for quality and safety. These RJ45 jacks are 14.5mm wide by 16mm high and are easily able to fit in most standard keystone jack wall plates. Plus, they come in a variety of colors – both to help you keep your cables organized but to also allow you to match your keystone easily to whatever colors you are planning.
You can find a variety of keystone wallplates with us, which allow you to easily customize what you put into each wall plate in your home. You could combine one of these with a coax keystone, or even a RJ11 keystone, with just an easy snapping of each keystone into their place.
Quality to Last a Lifetime
All FireFold keystone jacks come with a lifetime warranty. So, if something goes awry and it is the product causing the issue, we’ll be more than happy to replace it for you – hassle free! Go ahead and get your hands on one, or many, of these today!
Snap in tabs for easy installation
Available in a variety of colors
Interchangeable with many industry brands
Dual T568A and T568B wiring options
Four by four termination layout
Individually packaged

Housing Material: PC UL 94V-0 rated
Insert Material: PC UL 94V-0
Contact Finish: 50 micro inch gold; nickel plated 50-60 micro inch
IDC Housing: PC UL 94V-0 beige color
IDC Terminal: Phosphor Bronze, nickel plated 50-60 micro inch
Jack Housing Color: Beige
P.C.B: FR4 1.6m/m thickness, 2 layers
I.D.C CAP: PC UL 94V-0 black color
Certifications: ETL component; UL listed; ANSI/TIA/EIA-568-B.2;ISO/IEC 11801 Class E; FCC
Supports: Dual T568A and T568B wiring compatible with Category 5 enhanced requirement
