Electrical:
1.Rating: 50mA 12V DC
2.Travel:0.35±0.1mm
3.Contact Resistance :100mΩ Max
4.Electrically Life:100000 cycles Min.
5.Operating Force:180±50gf
6.Environment temperature:-30ºC~+80ºC

Materials:
1.Insert:H62Y &=0.30,Silver
2.Base:PPA,Blue
3.Shrapnel:Stainless steel
4.Waterproof membrane:Silica gel
5.Cap:PPA,Blue
6.Tensile plate:H65M &=0.30,Copper tin

KLS7-TS7785.pdf
