1- Center Contact: Brass,Silver-plated
2- Body-diecast:   Brass,Nickel-plated
3- Insulation:     PTFE
4- Crimping suite: copper alloy, nicked or Gold-plated
5- Electrical
    Impedance: 50 Ω
    Frequency Range:6 GHz Max.
    Insertion loss:≤0.35dB,DC-6GHz
    Insulation resistance:≥1000mΩ
    Voltage Rating: 2700 volts
    Withstand Voltage:4000V
    V.S.W.R:＜1.3
    Insulation resistance: 5000 MΩ Min.
    Contact resistance:
      Centre contact:0.4 mΩ
      Outer conductor:1.5 mΩ
6-Mechanical
   Mating: M29x1.5 threaded coupling
7-Durability(mating):  500 cycles  Max.
8-Temp.range   -40°C~85°C
Cable Type: RG393,RG213
