Material:
Insulator: PBT Rated UL94V 0
Contacts: Brass
Shell: Cold Rolled Steel
Pin Plated: Gold 3u” over 50u” nickel

Electrical:
Current Rating: 1.0 Amps Max.
Contact Resistance: 30 mΩ Max
Insulation Resistance: 1000 MΩ Min
Dielectric Withstanding Voltage:500 VAC / Minute

Mechanical:
Mating force: 3.0Kg Max. (29 4N)
Unmating force: 0 5Kg Min (4 9N)
Contact Retention: 0.3 Kg / Pin Min. (2.94N)
Operating Temperature: -55ºC~ +105ºC
