Material：
Screw:         M2.5,Steel, Zn plated
Cage:           Brass,Nickel plated
Pin header:  Brass , Tin plated
Housing:      PA66 , UL94V-0

Electrical：
Rated voltage:    300V
Rated current:    15A
Wire range:      26~14AWG  1.5mm²
Contact Resistance: 20 m Ω
Insulation resistance:  500MΩ/DC500V
Withstand voltage:      AC2000V / 1 min

Mechanical：
Temp. Range:    -40 ° C ~ + 105 ° C
Soldering:        250° C±5° C   for   5S
Torque:            0.4Nm(3.54Lbin)
Strip length:    6~7 mm

KLS2-107-5.08.pdf
