5.00mm Pitch Pluggable Terminal Block / 5.08mm Pitch Pluggable Terminal Block

Electrical:
Rated voltage: 300V
Rated current: 10A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding Voltage: AC2000V/1Min

Material:
Housing: PA66, UL94V-0
Contact: Stainless steel

Mechanical:
Temp. Range: -40ºC~+105ºC
Wire range:26-12AWG 2.5mm²
Strip length: 10-11mm

KLS2-EDKD-5.00/KLS2-EDKD-5.08.pdf
