Electrical:
1.Rating:50mA 12V DC
2.Contact Resistance:100mΩ Max.
3.Insulation Resistance:100MΩ Min,100V DC
4.Dielectric voltage proof:250V AC for 1min
5.Electrically Life:100000 cycles Min.
6.Operating Force:160±50gf
7.Environment temperature:-30ºC~+80ºC

Materials:
1.Cards: Phosphor, Silver plated
2.Pedestal:LCP,White
3.Shrapnel:Stainless steel
4.Push button:LCP,Black
5.Cover:H62, Silver plated

KLS7-TS2402.pdf
