It is characterized by stable technical performance, high efficiency, small volume, high protection grade and high seismic grade.
 Air cooling design.

Application:
  New energy vehicle
 Industrial control products
 Energy storage   power station
 IDC Data Center
 Product size: 250*196*98mm (without plug-ins)
 Product weight: 2.5kg
 Rated input voltage: 144Vac/336Vac/384Vac (customizable)
 Rated output voltage: 14Vdc
 Maximum output current: 143A
 Rated output power: 2KW
 Maximum output power: 2.4KW
 Efficiency: 95%
 Protection level: IP67
 Communication port: CAN2.0
