Electrical Specifications:
Insertion Loss: 1-65MHZ -1.0dB MAX
Return Loss: 1-10MHZ -20.0dB MIN
10-30MHZ -1 6.0dB MIN
30-60MHZ -12.0dB MIN
60-80MHZ -10.0dB MIN
Cross Talk: 10-30MHZ -40.0dB MIN
30-60MHZ -35.0dB MIN
60-100MHZ-30.0dB MIN
CMR: 1-50MHZ -30.0dB MIN
50-1 50MHZ -20.0dB MIN
Hipot: 1000V AC 6S 1mA
OCL: 350uH MIN @ 100KHZ 100mV 8mA DC
