ELECTRICAL:
RoHS peak wave solder temperature rating 235℃
High performance for maximum EMI suppression
350uH minmum OCL with 8mA bias current
PoE rating: 15W,350mA,48V (For PoE Products only)

MECHANICAL:
JACK CAVITY CONFORMS TO FCC RULES AND
REGULTIONS, PART 68 SUBPART F.
INSERTION FORCE: 2 CONTACTS—-350g     4 CONTACTS—-500g
6 CONTACTS—-750g     8 CONTACTS—-900g
10 CONTACTS—-1050g
RETENTION STRENGTH: 7.7Kgs BETWEEN JACK AND PLUG

DURABILITY:
750 MATING CYCLES Mini

KLS12-GL002.pdf
